12F GT
Forwarder de 20 de tone sigur pentru condiții dificile
Logset 12F GT este cel mai mare forwarder din gama Logset. Această mașină transportă cel mai mare volum de lemn posibil. Datorită motorului puternic de 291 CP și a forței de tracțiune amplificate de 262 kN, puterea Logset 12F GT este foarte impresionantă. Forwarder-ul are tehnologie nouă îmbunătățită și multe caracteristici orientate către utilizator. Noul sistem brevetat de asistență la frânare și protecție (DeX) permite performanțe excelente pe cele mai dificile terenuri.
BCA Solution
*Dealer autorizat
vezi acum
TEHNOLOGII
Noul sistem brevetat DeX
DeX este un asistent inteligent de frânare al motorului care controlează forwarder-ul în situațiile care necesită un moment de frânare al motorului mai mare, de exemplu atunci când se conduce în coborâre pe pante abrupte. DeX nu numai că îmbunătățește siguranța și confortul operatorului, dar protejează și motorul de supraregim. Acest lucru crește durata de viață a componentelor motorului și transmisiei.
Compartiment de încărcare pentru a transporta totul
Compartimentul de încărcare puternic, reglabil și durabil transportă mai mult lemn ca niciodată.
Logset 12F GT poate fi încărcat cu 30 m³ de bușteni.
Forță de tracțiune pentru condiții dificile
Logset 12F GT are o forță de tracțiune excepțională de 262 kN. Forwarder-ul funcționează chiar și pe cele mai dificile terenuri. Este puternic, precis și fiabil.
Cu ajutorul anvelopelor de 28,5″, forwarder-ul transportă chiar și cele mai grele sarcini.
Echilibru bun, flotabilitate excelentă, suficientă putere pentru mai multe sarcini simultane. Toate lucrurile simple, de bază, pentru ca pilotul să reușească pe parcursul întregii zile. Și știm, ziua poate fi cu adevărat lungă!
Sistem total de operare și control 2 (TOC 2)
Forwarder-ul este echipat cu sistemul de control al mașinii Logset TOC 2, ușor de utilizat. Datorită sistemului de control, operatorul economisește o mare cantitate de combustibil, iar experiența de conducere este lină și ușoară. Controlul macaralei este, de asemenea, rapid și precis. Dacă mașina are mai mulți operatori, aceștia își pot salva setările personalizate pentru macara.
SPECIFICAȚII TEHNICE
Dimensions
| Own weight, from | 24 000 kg (52 900 lbs) |
| Load capacity | 20 000 kg (44 100 lbs) |
LOAD AREA
| Load area | 5,4 – 6,6 m² |
| Load area length | 4,8 m (189″, 15.8 ft) – 6,2 m (244″, 20.3 ft) |
ENGINE
| Type | AGCO Power 74 LFTN |
| Stage | EU Stage V, EPA Tier 4 final |
| Power at 1850 rpm | 214 kW (291 hp) |
| Torque at 1500 rpm | 1 280 Nm (940 ft lb) |
| Fuel tank | 248 l (65 US gal) |
| DEF | 30 l (8 US gal) |
TRANSMISSION
| Type | Hydrostatic mechanical |
| Tractive effort | 262 kN (58 900 lbf) |
| Gear box | 2 gears |
HYDRAULIC SYSTEM
| Pump size | 180 cm³ |
| Pressure | 24 Mpa |
| Hydraulic oil tank | 175 l 46 US gal) |
CABIN
| Control System | TOC 2 |
| Battery voltage | 24 V |
Safety tested and approved cabin
TYRES
| Standard | 780/50-28.5 |
| Optional | 710/55-28.5 |
CRANE OPTIONS
| Crane | Mesera 142 F |
| Reach options | 8,1/10 m (26.6/32.8 ft) |
| Lifting capacity | 178 kNm (131 200 ft lb) |
| Rotator | 360° |
OPTIONAL EQUIPMENTS
Contact your local dealer for more information about options.
| Own weight, from | 24 000 kg (52 900 lbs) |
| Load capacity | 20 000 kg (44 100 lbs) |
| Load area | 5,4 – 6,6 m² |
| Load area length | 4,8 m (189″, 15.8 ft) – 6,2 m (244″, 20.3 ft) |
| Type | AGCO Power 74 LFTN |
| Stage | EU Stage V, EPA Tier 4 final |
| Power at 1850 rpm | 214 kW (291 hp) |
| Torque at 1500 rpm | 1 280 Nm (940 ft lb) |
| Fuel tank | 248 l (65 US gal) |
| DEF | 30 l (8 US gal) |
| Type | Hydrostatic mechanical |
| Tractive effort | 262 kN (58 900 lbf) |
| Gear box | 2 gears |
| Pump size | 180 cm³ |
| Pressure | 24 Mpa |
| Hydraulic oil tank | 175 l 46 US gal) |
| Control System | TOC 2 |
| Battery voltage | 24 V |
Safety tested and approved cabin
| Standard | 780/50-28.5 |
| Optional | 710/55-28.5 |
| Crane | Mesera 142 F |
| Reach options | 8,1/10 m (26.6/32.8 ft) |
| Lifting capacity | 178 kNm (131 200 ft lb) |
| Rotator | 360° |
Contact your local dealer for more information about options.
TEHNOLOGII INTEGRATE
TOC-MD 2
Logset machines are operated and controlled by our advanced control system TOC-MD 2
CUSTOM CONTROLS
You can customise many of our controls to suit your needs. No need to search buttons, just place them as you want
CRANE TILT
Crane tilt is a very usable option when working on demanding terrain
CABIN TILT & ROTATION
The harvester cabin adjusts with the differences in terrain so you will always sit nice and straight. The adjustable cabin rotation allows you to have the best possible view
MAINTENANCE IN MIND
Logset machines are built to be kept in good shape. Several advanced solutions makes Logset service easy: Components and service points are placed for maintenance. All essential components are accessible. Diesel and hydraulic oil tanks are easy to turn sideways for maintenance. The radiator is easy to clean in minutes. All filters are placed on the sides of the engine bay, where the side plates are quick to remove.
LOW FUEL CONSUMPTION
All the power you need, with low fuel consumption. Our machines have plenty of power to use wisely. All for making it easy for the environment and your costs.
LET THERE BE LIGHT!
You cannot cut what you don’t see. An optimal light field together with wide visibility from the Logset cabin gives you a better, stress-free and safe work environment.
The stylish and robust light guard gives strength and adjustability for optimizing your needs.
AGILE IS MY NAME
Logset harvesters are very agile. The wheels follow sharply in the tracks, and even tight turns are possible to make with great balance. Good agility makes it possible to harvest small to medium-sized sites with a bigger harvester. That gives the operator the advantage of being able to work with all-size fellings.
STRONG BODY FOR STRONG PEOPLE
Logset machine chassis is heavily based on the original design from the 90’s. It was built to be the most durable machine of the woods. And yes, we still have some of those 30yr old machines in use today. The strong body affects durability, but also the overall balance and grip of the machine when working on big loads. A good body is one of the keypoints of great machine.
CABIN DOOR CLOSE AID
A simple, but good gadget: Your cabin door can be opened/closed with one finger. The pneumatic door closing handle is handy when working on windy days or steep terrains.
TOC-MD 2
Logset machines are operated and controlled by our advanced control system TOC-MD 2
CUSTOM CONTROLS
You can customise many of our controls to suit your needs. No need to search buttons, just place them as you want
CRANE TILT
Crane tilt is a very usable option when working on demanding terrain
CABIN TILT & ROTATION
The harvester cabin adjusts with the differences in terrain so you will always sit nice and straight. The adjustable cabin rotation allows you to have the best possible view
MAINTENANCE IN MIND
Logset machines are built to be kept in good shape. Several advanced solutions makes Logset service easy: Components and service points are placed for maintenance. All essential components are accessible. Diesel and hydraulic oil tanks are easy to turn sideways for maintenance. The radiator is easy to clean in minutes. All filters are placed on the sides of the engine bay, where the side plates are quick to remove.
LOW FUEL CONSUMPTION
All the power you need, with low fuel consumption. Our machines have plenty of power to use wisely. All for making it easy for the environment and your costs.
LET THERE BE LIGHT!
You cannot cut what you don’t see. An optimal light field together with wide visibility from the Logset cabin gives you a better, stress-free and safe work environment.
The stylish and robust light guard gives strength and adjustability for optimizing your needs.
AGILE IS MY NAME
Logset harvesters are very agile. The wheels follow sharply in the tracks, and even tight turns are possible to make with great balance. Good agility makes it possible to harvest small to medium-sized sites with a bigger harvester. That gives the operator the advantage of being able to work with all-size fellings.
STRONG BODY FOR STRONG PEOPLE
Logset machine chassis is heavily based on the original design from the 90’s. It was built to be the most durable machine of the woods. And yes, we still have some of those 30yr old machines in use today. The strong body affects durability, but also the overall balance and grip of the machine when working on big loads. A good body is one of the keypoints of great machine.
CABIN DOOR CLOSE AID
A simple, but good gadget: Your cabin door can be opened/closed with one finger. The pneumatic door closing handle is handy when working on windy days or steep terrains.
